Detailed Product Description
High Light:

automated spray booth

,

industrial spray booths



Aluminum Powder Coating Production Line With Immersion Tank Pretreatment System





Quick Detail:



1. The picture shows moisture drying oven, its pretreatment is dip-type, conveyor system in this line is rhythm controlled.

2. This coating production line's pretreatment is dip-type, the conveyor system is rhythm controlled. the conveyor chain, pneumatic door and the action of powder-immersion are controlled by PLC



Aluminum Powder Coating Production Line With Immersion Tank Pretreatment System 0



Design parameter





No.



item



Design basis

1

workpiece



aluminum

2



Maximum thickness of material

≤1.2mm

3



Pre-treatment method



Immersion pre-treatment

4



spraying method of powder



Automatic + manual

5



The maximum size of workpiece hanged on the assembly line

           L×W×H=6800×200×1900(mm)

6



Maximum weight of work piece



≤70Kg/hanger(including balance beam)

7



Hanging method



Double points hanging

8



Suspension conveyor chain on the assembly line



QXG-200 model,hanging weight  max 35kg

9



Scissors film pitch on the assembly line



7200mm/2pieces

10



process speed calculation on the assembly line



Processing speed: 0.8m/min

11



Production line speed range

0~1.5m/min adjusted

12



Powder curing temperature



180~200℃(liquid gas direct heating)

13



Powder coating time



16min-20min(except to air curtain section)

14



Heating source of curing tunnel



liquid gas direct heating

15



Dehydration  oven:



≤110℃(liquid gas direct heating)








moisture drying oven



Appearance size: (L)7600mm×(W)2200mm×(H)1850mm



Material: outer board,δ=1.0mm  cold rolled corrugated steel board

Inner board,δ =1.0mm galvanized board



Insulation thicknessδ=100㎜,



Insulation material:Rockwool;



Drying temperature: ≤110℃(aluminum)



The highest heating: 110℃≤60min,

Combustion gas machine model:  RIELLO FS20



Output heat quantity: 200000 kcal/h,



Efficiency of the air heat exchanger 90%,



Process parameters and material list of curing tunnel



No.



name



    data

1



External size of drying tunnel:



21000mm×940(1240)mm×3720mm

2



Internal size of drying tunnel section:



(W)700mm×(H)3050mm(refer to the layout)

3



The model of  drying tunnel:



straight-through

4



Thickness of the insulated board:

,

Side board:150mm, roof/bottom board:150mm

5



Inner and outer plate of insulation layer:



Internal board:δ0.8 galvanized board, outer board:δ0.8 color coated board

6



Sending wind tube:



δ 1.0mm galvanized board

7



Natural exhaust device:



2 pieces

8



Pedestal height:

430mm

9



Sending wind method:



side to send side up to back

10



Effective drying length:



About 18m( except to the length of air curtain section)

11



Baking time:



About 16min-20min

12



Heating time (empty furnace):



About 40min

13



Heating temperature:



Normal temperature~200℃ adjustable

14



Cycle times:



About 4 pieces/min

15



200000 kcal stainless steel heat exchanger



1set

16



200000 kcl heat exchange box:



1 set(outer plate:δ1.o mm cold plate, inner plate:δ1.o mm galvanized board)

17



Thermal induced draft fan:



1set(4.0KW)with 6#impeller  air volume about:10000m3/h

18



combustion gas engine:



1 set FS20 (200000 kcal)

19



Air curtain machine:



2sets



Aluminum Powder Coating Production Line With Immersion Tank Pretreatment System 1



powder  spray room and powder room isolation room



No.

name

    data

1

Outer size of powder room:

6000mm×1400mm×3600mm(refer to layout)(1set)

2

Material of powder room:

sidetopbottom board: δ1.5mm cold board (surface spraying)

3

Closed-circuit system

1set

4

Automatic electrostatic sprayer:

6sets

5

Manual sprayer



2sets

6

8 cores recycling

 of the upper and lower device

2(hot plate and cold plate to make) the height of filter:660mm

7

Recover fan

2sets(7.5Kw)air volume:10000m3/set



8



Explosion-proof fluorescent lamp;

Each 1 piece of unilateral

9



Isolation room:



7.5m×5.2m×4.0m,chamber body adopts aluminum alloy frame and 50㎜sandwich board structure



Aluminum Powder Coating Production Line With Immersion Tank Pretreatment System 2



Suspension conveyor system:

No.

name

Specification

1

Suspension chain model:

QXG-200

2

Pitch:

200mm

3

Single point of hoisting:

≤35Kg(including the spreader)

4

The total length of suspension chain:

82m


Aluminum Powder Coating Production Line With Immersion Tank Pretreatment System 3
