Porous titanium sintered plates
filter fineness :0.2µm -50µm.
Size:T0.6mm-6mm*W260mm*1000mm
Porous Titanium Sintered filter for high temperature gas separation
Outer surface of the light Titanium filter through special processing
smooth , have a long service life , easy to clean . as the outside light
sinter metal particulate filter smooth surface, poor adhesion of impurities, titanium rod
ttached to the filter surface impurities reaches a certain weight,coupled
with the media swirl momentum will naturally fall off from the great wall of
the fitler to reduce the titanium rod filter core black , and thus greatly
extend the sinter metal particulate filter cleaning cycle , outer wall smooth ,in line
with the GMP requirements .
Application:
It is used for powder gas separation, powder metallurgy ,miming industry and
other slid gas separation.
The main parameters:
Filtration precision;0.22um-100um,20-50% porosity
Compressive strength:0.5-15Mpa
Temperature:MAX 300 degree
Maximum working pressure :0.6Mpa
Specifacation:
Diamerer:30mm,40mm,50mm,60mm,80mm
Length:125mm,250mm,300mm,500mm,750mm,1000mm
Interface Type:threaded M20,M30,M36,M42,Planar 215,220,222,226,Flange
Application:Asseparation and filtrationinpetrochemical industry, liquid medicine manufacturing, medical equipment and other basic industries
Productive process :Titanium powder→ sieve → mixing → rolling → sintering → leveling → porous titanium plate
| Filter rating | Filtration precision (µm) | The largest aperture(µm) | Osmosis system
10-12m2 | permeabilitym3/h.m2.kpa | The thickness (mm) | Compressive strengthMpa/cm2 |
| T9 | 0.2 | 2.5 | | 1.5 | 3 | 3 |
| T8 | 0.5 | 4 | | 3 | 3 | 3 |
| T7 | 1 | 6 | | 5 | 3 | 3 |
| T6 | 2 | 10 | | 15 | 3 | 3 |
| T5 | 5 | 15 | 0.04 | 40 | 3 | 2.5 |
| T4 | 10 | 30 | 0.15 | 120 | 3 | 2.5 |
| T3 | 20 | 60 | 1.01 | 250 | 3 | 2.5 |
| T2 | 30 | 100 | 2.01 | 500 | 3 | 2.5 |
| T1 | 50 | 160 | 3.02 | 800 | 3 | 2.5 |
