Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width

Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width

    • Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width
    • Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width
  • Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width

    Product Details:

    Place of Origin: Wenzhou, China
    Brand Name: CHANGJIANG
    Certification: CE ISO9001
    Model Number: CJGT-600

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Packaging Details: Standard export package
    Delivery Time: 30 Days after deposit
    Payment Terms: 30% T/T payment in advance, 70% T/T payment before shipment
    Contact Now
    Detailed Product Description



    Custom Made Oil Filter Rotary Pleating Machine , 600mm Max Width





    Quick Detail:



    -  Easy to adjust the roller

    -  Good looking of the filter surface

    -  600mm machine width





    Consists



    1.  Auto Paper de-coil

    2.  Paper pre-slitting machine

    3.  Pre-heating device before pleating

    4.  Auto counter

    5.  Water steam device

    6.  Rollers marking machine

    7.  Roller and gear collecting machine

    8.  Pleated paper heat forming and conveyer device





    Specifications:



    Product capability 0-35m/min
    Max width 600mm
    Min width 30mm
    Max pleat height 50mm
    Min pleat height: 20mm
    Temp. control 0-300℃
    Main power 12kw
    Working air pressure 0.6MPA
    Power supply 380V/50HZ
    M/C weight 750kg
    M/C dimension 3600*1170*1200mm





    Features



    1. The pre-slitter uses pneumatic cutting round knife, which is adjusted simply and pressed evenly.

    2. This machine equips the pre-heating and water steam device to prevent the paper breaking when roller marking,

    3. This machine equips the gear collecting system, so to faster the pleating speed and well pleated the paper.

    4. The rollers can be made with bubbled type or the pleat-lock type, which is used to maintenance the certain distance between two pleats.

    5. This high automatic machine has the process of the auto counting, pleating pre-heating and forming

    6. This machine is computer control and simple operation.





    Applications



    This machine is used for pleating and forming ECO filter element
