Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price

Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price

    • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
  • Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price

    Product Details:

    Place of Origin: China, mainland
    Brand Name: zw-hovvo
    Certification: CE, ISO, CCC, CE, BV, WMI
    Model Number: zwtrailer1505

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD6000-20000 per unit
    Packaging Details: packed as nude
    Delivery Time: within 25 days after yr deposit
    Supply Ability: 2000 sets per month
    Contact Now
    Detailed Product Description
    Color: Optional Material: Aluminum Alloy / Qabon Steel / Stainless Steel Material
    Condition: New Or Used Tank Volume: 36000-50000liters
    Axle Brand: RJST / BPW / FUWA Optional Suspension: Common Mechanical Or Air Suspension
    Dimensions (L X W X H) (mm): 11700*2500*3750mm Compartment: 3 Compartments
    Application Or Use: Oil Fuel Transport Shipping Condition: 40HC 45HC Container, Bulk Vessel, Or Ro Ro Vessel

    Aluminum Alloy Qabon steel  Stainless Steel Material Tri-axle 36000 Litres Fuel Tanker Truck Semi Trailer Price

    Description

    1. Main frame is made of high strength low alloy steel, which can fully enhance its abilities of resistance to torsion, anti-seismic and anti-jolt, and meet the various loading requirements.
    2. The tanker is produced with the special equipments such as automatic welding machine(8m) and CNC plasma cutting and automatic submerged arc welding forming which can realize welding by one side in shape by two sides, having the merits of stable quality, less cost, and good-looking
    3. Sophisticated technique: Main parts of the trailer is processed with advanced equipment. The longitudinal beam is welded by a wholly automatic tracking submerged welding machine; Almost the steel spare parts are treated by shot blast before the assembling, which can greatly increase the adhesion of the paint.
    4. Frame: The frame is manufacture by a structure, which are made of high strength steel. This design reasonably to get a balanced consideration of the intensity, rigidity and toughness, advantages of low tare weight, heavy loading mass, not easy to be distorted.
    5. Axles: The axle can be selected in different famous brand of BPW and SAF, KIC, FUWA ect. domestic and overseas. Also, the ABS system can be optional with Haldex and WABCO etc., can be greatly increase the stability and safety.
    6. Suspension system: Mechanical suspension and air suspension series optional.


    Oil tanker Trailer Specifications &Configuratgion

    Fuel tank semi trailer Specification

    Tank Body Shape

    Square Round/ Ellipse

    Model Name

    50000l oil tank

    Function

    oil and fuel trailer

    Overall Dimension

    (L*W*H) 11700*2500*3750mm

    Volume

    50m3 3compartments

    Tare weight

    10500KG

    Tank shell

    Q235B/5mm

    Dish end

    Q235B/5mm

    Baffle

    Q235B/4mm

    Spoil box

    Zinc galvanized type

    Manhole flange

    Q235B/5mm, 20 inch manhole

    Piping system

    2 sets of2’ steel pipes under tank body

    Discharge valve

    2 units of DN100 ball valves fixed at bottom of Tank

    Manhole cover

    2 sets of 500mm/Q235 manhole fixed on top of Tank, with breather valve

    Chassis



    Main beam

    Heavy duty and extra durability designed; Opting for high tensile steel Q345B
    with 500mm, welded by automatic Submerged-Arc processes.
    top flange 14mm, bottom flange 16mm and web 8mm reinforcement


    Axle

    3 axle 13T Fuwa Brand

    Suspension system

    Mechanical Suspension

    Steel Spring

    10/10/10 leaf spring suspension

    Tire

    12R22.5 12pcs

    Rims

    9.0, 12 pieces

    Discharge valve

    4''disc valve ,3pcs

    Discharge pipe

    4''seamless steel tube ,3pcs

    Spare Wheel Bracket

    2'' bolt-in king pin

    Landing gear

    Fuwa brand two-speed,manual operating ,heavy duty landing gear 20t

    Tool box

    one piece

    Compartment

    Three

    Braking system

    RE6 relay valve ;T30/30 spring brake chamber;40L air tanks

    Electrical system

    voltage:24V 2.Receptacle:7ways(7wire harness)



    Tail lamp with turn signal,brake light&reflector,side lamp etc.



    One set 6-core standard Cable

    Accessories

    One standard tool box.fire extinguisher 2 pcs

    Painting

    Sand blasting processing on rust cleaning before painting, One coat of
    paint Primer layer, Two coats of finish paint final coat

    Packing

    Polish with wax before shipping

    Remark

    If u need a pair of petrol pump and fuel nozzle, US$1870 will be
    charged addtionally


    Truck Trailer in details, production and transportation
    Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
    Aluminum Alloy / Qabon steel / Stainless Steel Material Tri-axle 50000 Litres Fuel Tanker Truck Semi Trailer Price
