Vehicle Spare Parts Gcr15 6203 - 2RS Ball Bearing for transmission

Vehicle Spare Parts Gcr15 6203 - 2RS Ball Bearing for transmission

  • Vehicle Spare Parts Gcr15 6203 - 2RS Ball Bearing for transmission
Vehicle Spare Parts Gcr15 6203 - 2RS Ball Bearing for transmission
Product Details:
Place of Origin: China
Brand Name: LEI HUI
Certification: ISO9001
Model Number: 6203
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: negotiation
Packaging Details: Middle box+Outer carton
Delivery Time: According to your order
Payment Terms: T/T
Supply Ability: 500,000-1,000,000PCS/Year
Contact Now
Detailed Product Description
Vibration: Z1V1,Z2V2,Z3V3 Cage: Stamping Steel,Brass,Nylon
Material: Gcr15,Stainless Steel,Carton Steel,Plastic,Ceramic Precision Rating: P0,P6,P5
Clearance: C0 C1 C2 C3 Sealed Type: 2Z,2RS,RS
Vibration: Z1V1,Z2V2,Z3V3
High Light:

single row deep groove ball bearing

,

precision ball bearings


Vehicle Spare Parts Gcr15 6203 - 2RS Ball Bearing for transmission





Description:



Deep groove ball bearing is a kind of the most common rolling bearing. The basic type of deep groove ball bearing is composed of an outer ring, a ring, a group of steel ball and a group of retainers. Deep groove ball bearing has a single row and double row two types, and also has sealed bearing and open bearing, open refers to the bearing without sealing structure,sealing type deep groove ball into the dust seal and oil seal. Dust seal cover material for steel plate stamping, plays only a simple prevent dust from entering the bearing raceway. Oil proof type contact type oil seal, can effectively prevent bearing grease inside the spillover.



Applications:

Deep groove ball bearing can be used for transmission, instruments and meters, electric machinery, household electrical appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, engineering machinery, roller skate,yo-yo etc.



Specifications:


New model Diameter Weight
  d
(mm)
D
(mm)
B
(mm)
W
(kg)
6200 10 30 9 0.031
6201 12 32 10 0.036
6202 15 35 11 0.043
6203 17 40 12 0.065
6204 20 47 14 0.104
6205 25 52 15 0.147
6206 30 62 16 0.205
6207 35 72 17 0.285
6208 40 80 18 0.37
6209 45 85 19 0.408
6210 50 90 20 0.46
6211 55 100 21 0.60
6212 60 110 22 0.8
6213 65 120 23 1.05
6214 70 125 24 1.13
6215 75 130 25 1.16
6216 80 140 26 1.49
6217 85 150 28 1.81




deep groove ball bearing

6000series

6000,6001,6002,6003,6004,6005,6006,6007,6008,6009,6010,6011,6012,6013,6014,6015,6016,6017,
6018,


6200series

6200,6201,6202,6203,6204,6205,6206,6207,6208,6209,6210,6211,6212,6213,6214,6215,6216,


6300series

6300,6301,6302,6303,6304,6305,6306,6307,6308,6309,6310,6311,6312,6313,6314,6315,


6400series

6403,6404,6405,6406,6407,6408,6409,6410,6411,6412,6413,6414,6415,6416,6417,6418,6419,6420


Thin-section deep groove ball bearings

6700ZZS,6800ZZ,63800ZZ,6900ZZ,6701ZZS,6801ZZ,63801ZZ,6901ZZ,6702ZZS,6802ZZ,63802ZZ,6902ZZ,
6703ZZS,6803ZZ,63803ZZ,6903ZZ,6704ZZS,6804ZZ,63804ZZ,6904ZZ,6805ZZ,63805ZZ,6905ZZ,6806ZZ,
3806ZZ,6906ZZ,6807ZZ,6907ZZ,6808ZZ,6908ZZ,6809ZZ,6909ZZ,6810ZZ,6910ZZ,6811ZZ,6911ZZ,6812ZZ,
6912ZZ,6813ZZ,6913ZZ,6814ZZ,6914ZZ,6815ZZ,6915ZZ,6816ZZ,6916ZZ,6817ZZ,6917ZZ,6818ZZ,6918ZZ


16000series

16001,16002,16003,16004,16005,16006,16007,16008,16009,16010,16011,16012,16013,16014,16015,
16016,16017,16018,16019,16020,


Inch R-series

R156,R166,R3,R3A,R168,R188,R4,R4A,R6,R1212ZZ,R8ZZ,RLS4ZZ,RMS4ZZ,R1458ZZ,R10ZZ,RLS5ZZ,
RMS5ZZ,R1634ZZ,R12ZZ,RLS6ZZ,RMS6ZZ,R14ZZ,RLS7ZZ,RMS7ZZ,R16ZZ,RLS8ZZ,RMS8ZZ,R18ZZ,
RLS9ZZ,RMS9ZZ,R20ZZ,RLS10ZZ,RMS10ZZ,R22ZZ,RLS11ZZ,R24ZZ,RLS12ZZ,


1600series

1601,1602,1603,1604,1605,1606,1607,1614,1615,1616,1620,1621,1622,1623,1628,1630,1633,1635,


Double row (4200A,4300A)

4200,4201,4202,4203,4204,4205,4206,4207,4208,4228,4210,4301,4302,4303,4304,4305,4306,4307,
4308,4309,4310


W6000,W6200,W6300 series

W6000,W6001,W6002,W6003,W6004,W6005,W6006,W6007,W6200,W6201,W6202,W6203,W6204,
W6205,W6206,W6207,W6208,W6209,W6210,W6211,W6300,W6301,W6302,W6303,W6304,W6305,
W6306,W6307,W6308,W6309,


62200 series

62200,62201,62202,62203,62204,62205,62206,62207,62208,62209,62210,62211,62212,62213,62214,
62215,62216,62217,62218,62219,62220,


62300 series

62300,62301,62302,62303,62304,62305,62306,62307,62308,62309,62310,2311,62312,62313,62314,
62315,62316,62317,62318,62319,


85000,86000 series

87500,87501,87502,87503,87504,87505,87506,87507,87508,87509,87510,87602,87603,87604,87605,
87606,87607,87608,87609,


60/** 62/** 63/** W*** series

60/22,60/28,60/32,62/22,62/28,62/32,63/22,63/28,63/32,279,317,319,348,382,98205,98206,98305,W204,W205,6303ZZV,6204ZZV,6005ZZV,6505,6908,

Competitive advantages:

Our company product and export bearings for 20years,so we have a deep knowledge of bearing.we can guarantee the quality and the price ,and we ensure our production can meet your requirement. In addition ,we can manufacture the production according your requirement.


Our company main production:

Deep Groove Ball Bearing / Angular Contact Ball Bearing/ Taper Roller Bearing/ Spherical Roller Bearing /Cylindrical Roller Bearing / Thrust Ball Bearing /Thrust Roller Bearing /Self-aligning ball bearing/Self-aligning roller bearing/Pillow Block Bearing /Needle Roller Bearing /Tracking Roller Bearing/ Auto Bearing Etc.
