HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system

HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system

  • HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
  • HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
  • HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
  • HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
  • HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system
Product Details:
Place of Origin: China
Brand Name: HOWO
Certification: ISO 9001-2000
Model Number: CVZZ3327M3811
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: Nude
Delivery Time: Within 30 days after the receipt of the deposit
Supply Ability: 100 units per week
Contact Now
Detailed Product Description
Color: Option Drive Type: 8x4
Engine Model: Euro II / Euro III Drive Mode: RHD/LHD
Drive Wheel: 8x4
High Light:

Heavy Duty Trucks

,

Heavy Dump Truck

HOWO 8x4 50t Heavy Duty Dump Truck , HYVA Hdraulic lifting system

Specifications

Model

CVZZ3317N3567W

Cab

HW76

Engine(Hp)

336/371

Power(Kw)

247/273

Transmission

HW15710/HW19710

Front Axle

HF9

Steering

ZF8098

Rear Axles

HC16

Wheels & Tyres

8.5/12.00-20

Carriage Internal

Dimensions(mm)

7300x2300x1500

Cubage (m3)

25.2

Steel thickness of

Carriage(mm)

Floor:8mm/Side:6mm

Hydraulic Lift of

Carriage

Front Lift

Dimensions (mm)

10245×2496×3170

Kerb weight

14860

Engine

Model

WD615.69

WD615.47

Horsepower

336

371

Maximum output

Kw/r/min

247/2200

273/2200

Maximum torque

N.m/r/min

1350/1300-1600

1460/1300-1600

Type

6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled

direct injection

Bore x Stroke

126x130mm

Valve

2

Displacement

9.726L


Make SINOTRUCK (CNHTC), Euro II emission standard

Thermostat with 80 opening begin, Rigid fan

Cab

SINOTRUK HW76 Lengthen cab,single bunk,new type seat,adjustable steering wheel,EURO new type

heating & ventilating system, German VDO instruments,safety belts, exterior sun visor,

stereo radio/cassette recorderleft driving,air conditioner

Option: right driving; color

Clutch

SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Transmission

SINOTRUK HW15710 or HW19710 transmission ,10 forward and 2 reverse

Ratio:14.28  10.62  7.87  5.88  4.38  3.27  2.43  1.80  1.34  1.00  13.91(R1)  3.18(R2)

Front Axle

SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes

Option: disc brake

Steering

German ZF8098 Steering Gear Box ,hydraulic steering with power assistance,Ratio:22.2-26.2

Rear Axles

HC16 Heavy reduction drive axle,STR hub-eduction with differential locks between wheels and axles,

enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be

used in such bad environment as bad road condition, heavy impact and overloading, which is the best

choice for heavy construction vehicle customers.

Brake System

Service brake:dual circuit compressed air brake

Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

Auxiliary brake:engine exhaust valve brake

Wheels & Tyres

Rims:8.5-20,10 hole-steel ;Tyres:12.00-20 diagonal tyre with 1 Spare tyre

Option:12.00R20 radial tyre



Electrics



Operating voltage:24V,negative grounded

Starter:24V,7.5 Kw

Alternator:3-phase,28V,1500 W

Batteries:2x12 V,165 Ah

Cigar-lighter,horn,headlamps,fog lights,brake lights,indicators and reverse light

Option:2x180Ah Batteries

Oil Tank

Square type-300L Aluminum alloy fuel tank

Delivery date

Within 45 working-days after receipt advance

Weight in kg

Gross vehicle weight                                                                       31000

Front axle loading capacity                                                             9000

Rear axles loading capacity                                                            2x16000

Performance

Maximum drving speed (km/h)                                                       75

Fuel consumption  (1/100 km)                                                 38

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard

packing of the manufacturer, be suitable for long distance transportation of ocean and inland.

The Seller shall be take measures against moisture,

shocks and rust according to the special needs of the commodity.

*The manufacturer reserves the right of technical alteration /change for better improvement without prior notice
