4 Color Flexo Printing Machine for roll paper printing / Plastic film

4 Color Flexo Printing Machine for roll paper printing / Plastic film

    • 4 Color Flexo Printing Machine for roll paper printing / Plastic film
  • 4 Color Flexo Printing Machine for roll paper printing / Plastic film

    Product Details:

    Place of Origin: RUIAN
    Brand Name: shelly
    Certification: CE
    Model Number: SH-600

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Packaging Details: WOODEN CASE
    Contact Now
    Detailed Product Description
    Width: 100-2000mm Speed: 50m/min
    Raw Material: Pe Paper Aluminum Foil
    High Light:

    flexo label printing machine

    ,

    Plastic Bag printing equipment



    4 Colors Flexo Printing Machine For  color high speed  printer for roll paper printing





     1.The main features



    1. Take it easy, accurate color, long life
    2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
    3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
    4. The use of special diagonal-tooth gear, print size is accurate,
    5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
    6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
    7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
    8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
    9. The Print produce are clear and good arrangement quality
    10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll





    2.Main Technical Parameter:



    Model

    600

    800

    1000

    1200

    1400

    1600

    Max. Material width

    650mm

    850mm

    1050mm

    1250mm

    1450mm

    1650mm

    Max. Printing width

    560mm

    760mm

    960mm

    1160mm

    1360mm

    1560mm

    Printing material

    Single adhesive paper,Double adhesive paper,Copper plate paper,Kraft paper :50-350g/m2

    Single filter membrance paper,Double filter membrance paper : 80-350g/m2

    Printing color

    4 special color

    Printing length

    7.5"-40"(190mm-1016mm)

    Printing plate lifting system

    Hydraulic press control

    Mechanical speed

    90m/min

    Printing speed

    10-70m/min

    Anilox roller

    Metal: 100-300LPI

    Or

    Ceramic anilx roller(200-1000LPI), single doctor blade

    Register precision

    Longitude:±0.25mm     Transverse:0.25mm

    Rewinder/Unwinder DIA

    ø 800mm/ ø 1000mm/ ø 1200mm/ ø 1500mm

    Master power

    26kw

    28lw

    32kw

    34kw

    36kw

    38kw

    Weight

    4800Kg

    5000 Kg

    5400 Kg

    5800 Kg

    6200 Kg

    7000 Kg

      Dimension (L×W×H)

    5.3m
    ×
    2.0m
    ×
    2.6m

    5.3m
    ×
    2.2m
    ×
    2.6m

    5.4m
    ×
    2.4m
    ×
    2.6m

    5.4m
    ×
    2.6m
    ×
    2.6m

    5.5m
    ×
    2.8m
    ×
    2.6m

    5.5m
    ×
    3.0m
    ×
    2.6m




     -----  With double unwind & double rewind unit





    1. The main features:



    1. Take it easy, accurate color, long life.

    2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.

    3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.

    4. Use special synchronous belt drive, accurate printing size.

    5. Two sets of heating devices, including central heating and constant temperature control system for group control.

    6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.

    7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.

    8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing

    9. Print produce are clear and good arrangement quality.

    10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll







    2. Main parameter:



    MODEL:

    886-600, 886-800, 886-1000,886-1200 etc.

    Printing Material:

    Plastic film

    OPP:20~80μm,BOPP:18~80μm,PE:35~100μm,

    NY:20~50μm,PET:12~60μm,CPP:20~60μm,

    paper: 20~150g/m2

    Machine color:

    6Color

    Max. Material width:

    (650mm up to 1650mm, width size depends on client need)

    Max. Printing width

    (550mm up to 1550mm, width size depends on client need)

    Max.printing length:

    200mm~1000mm

    Max. Machine speed:

    180m/min

    Max. Printing speed:

    30-150m/min

    Register precision:

    Crosswise:±0.20mm;Longitudinal:±0.20mm

    Plate thickness:

    Resin 2.28mm

    Double tap thickness:

    0.38mm(3M)

    Printing cylinder on machine:

    40cm/ 1 set

    Machine outside:

    5.4m(L)×2.0m(W)×3.4m(H)

    Machine total power:

    45Kw

    Voltage:

    Voltage 380V, 3 PH, 50 Hz







    3. Detailed parameter:





    3.1) Double unwind unit:



    Max. unwind diameter

    Φ800mm

    Unwind Way

    Center unwind, with 10KG powder magnetic and auto tension control 2pcs

    Tension precision

    ±0.3kg

    EPC System for unwind

    1pcs

    Unwind material holder

    By air shaft , 2 pcs

    Unwind web cylinder

    Φ76mm (inner diameter)



    3.2) Printing Unit:



    Principle of Work

    Belt Drive

    Suitable Printing Ink

    Water-based ink or Oil-based ink

    Material of Plate

    Resin or Rubber

    Constitution of Printing

    Chrome plated roller, Rubber roller, Anilox roller, Plate cylinder

    Anilox roller

    High speed machine:ceramic anilox roller (100-1000lpi), chamber doctor blade for 30-150m/min

    Printing Pressure

    Mechanical adjust

    Color register type

    By Manual

    Printing plate lifting system

    Automatic Hydraulic cylinder control roll up and down





    3.3) Heating and Drying Unit:



    Dryer

    Electrical heat drying

    Blower

    4kw x 1pcs

    Double Blower way circle

    Centralized heat, exhaust gas pumpback

    Power of Heating

    32 kw





    3.4) Double Rewind Unit:



    Max. rewind diameter

    Φ800mm

    Rewind Way

    Centre rewind;

    Tension control system

    Automatic tension control 2pcs

    Rewind material holder

    By air shaft , 2pcs

    Rewind motor

    1.5Kw, Taiwan motor

    Rewind web cylinder

    Φ76mm (inner diameter)





    Optional parts which extra cost buy:



    NO.

    Goods of Descriptions

    1

    Printing cylinder which use on flexographic printing machine

    2

    Corona treatment

    3

    Monitor system (also called image inspect device): screen+camera+controller

    4

    Pate mounting machine(easier to mount plate)

    5

    Plate making machine

    6

    Anilox roller cleaning machine ( especially client buy machine for paper printing)

    7

    Ink viscosity measurement ( 1 color need 1pcs)





    Applications

    Fully Automatic  Flexo Printing Machine For Non Woven

    Flexo Printing Machine For  Paper

    PLC Control Flexo Printing Machine For Non Woven Bag

    High Speed  Flexo Printing Machine For BOPP Film

    Auto  Flexo Printing Machine For Corrugated Carton

    Flexo Printing Machine For shopping bag

    CE Flexo Printing Machine For thermal paper

    PLC  Flexo Printing Machine For Plastic  shopping Bag

    flexographic printing machine For woven sacks

    Automatic  Flexo Printing Machine For Plastic Film
