High Efficiency U15 DOP ULPA Air Filter Commercial Air Filters With Hood

High Efficiency U15 DOP ULPA Air Filter Commercial Air Filters With Hood

  • High Efficiency U15 DOP ULPA Air Filter Commercial Air Filters With Hood
High Efficiency U15 DOP ULPA Air Filter Commercial Air Filters With Hood
Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: EN1822
Model Number: KEL-UD
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: NEGOATION
Packaging Details: CARTON
Delivery Time: 8 WORKING DAYS
Payment Terms: T/T, LC.CIF,CNF
Supply Ability: 2500PCS/month
Contact Now
Detailed Product Description
High Light:

commercial air filters

,

Mini pleat hepa filter

Compact U15 DOP ULPA Air Filter Commercial Air Filters With Hood





Quicky Detail:



Media: Glass fiber
Frame: Aluminum
Gasket: PU Foam
ULPA filter efficiency: 99.999%@0.3um  U15
ULPA filter size: 610x610X150mm
Resistance:<200pa
DOP Port: 1 pcs
Hood : Dimater 250-350mm


Company Information :


Keling Purification Technology Co., Ltd engaged in air purification field for many years, product have clean room equipment and air filter, such as Air shower room, automatic air shower room,Cargo air shower, Intelligent air shower, HEPA air shower room, class100 air shower room, clean air shower room. Air shower room tunnels,   dispensing booth, laminar air flow units, dynamic pass thrus, clean Pass box, pass thrus, portable clean shed,  Laminar flow bench, Hardwall cleanroom, softwall cleanroom, HEPA units,clean shed, clean booth, fan filter unit, Mini-pleats ULPA/HEPA filter, V-cell filter, pocket filter, panel filter, z-line filter, cleanroom aluminum fitting, sandwich panel, sticky mat and so on.



Performance:

It is high efficiency, Big media area, long time using life, Plenty air volume. Low resistance and less operate cost.



Applications area:

ULPA Air filter with hood widely use for operate room, laboratory room,

Microelectronics , film, optical machine, food workshop and so on where need high purification rank environment.



Characteristics:

1: The ULPA air filter with hood  is the finally filtration in clean room that use for filter the particles more than 0.12um.

 2:  high dust holding capacity, mini-pleats design,The filter media adopt the ultra-thin glass fiber , the hot-melt glue spacing each pleats in regular so that achieve high dust volume ,  all of the media area can be used in completely .

3: The sealant around the media so that the air filter without any air leaking

4: The anodized aluminum frame in light weight and easy install that ensure the anticorrosion performance.

5: the air filter including the air flange , the size cam be in ¢250, ¢300, ¢350 for your option

6: outside of the air filter is PEF cotton for prevention the temperature get cool.

7: The sealant around the media so that the air filter without any air leaking

8: laser to scan the each air filter one by one,

9: the air filter efficiency range:  U15.U16.U17, 99.9995-99.99995%@0.3um (EN1822).



Dimension and parameter:

Dimension

(W*H*D)

 (mm)

Air flow

(M3/h)

Media area

(m2)

Holding dust(g)

Primary resistance

(by0.5m/s)

Final

Resistance

pa

Efficiency

(0.3um)

610x610x120

1000

11

680

<200pa







400-600







H13-H14

915x610x120

1500

17

1000

<200pa

1170x570x120

1800

20

1200

<200pa

1220x610x120

2000

22

1350

<200pa

610x610x150

1250

14

906

<200pa

915x610x150

1900

21

1360

<200pa

1170x570x150

2200

23

1800

<200pa

1220x610x150

2500

27

350

<200pa

Customized size is available



Why you choose K-LING Company ?



Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.
• We cooperate with customer to bid tenders. Provide all necessory docuement.
• We are a sales team, with all techinical support from engineer team

Punctual delivery time:

• Production / inspection report provide before shipment
• Shipping notice or insurance for you when your goods is shipped.
After sales service:
• We respect your feed back after receive the goods.
• We provide one year warranty after goods arrive.
• We promise all spare parts available in lifetime use.
• We care of your complain within 48hours.


Payment Term:

 T/T in advance, 30% before place the order, 70% when you see copy BL
Or 30% T/T in advance before place the order, 70% LC at sight.
