Beijing Automobile Spare Part Co.,Ltd.
High quality, Best service,Reasonable price.
Place of Origin: | CHINA |
Brand Name: | UNITE |
Certification: | ASME, ISO, ABS |
Model Number: | U-ZC-G1 |
Minimum Order Quantity: | 1 set |
---|---|
Packaging Details: | Export Wooden Case |
Delivery Time: | 10-50 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 500 Set/Sets / Month |
Model: | Automatic Self Cleaning Filter | CODE: | GB OR ASME |
---|---|---|---|
MATERIALS: | CARBON STEEL /SS 304/SS 316L | SURFACE: | PAINTING /POLISHING |
Application: | Sea / River / Lake / Rain / Industrial Water Filtration | Filtration Rating (μm): | 0.2-50 Microns |
High Light: | multi cartridge filter housings,stainless steel water filter housing |
Automatic Self Cleaning Filter
Introduction:
U-ZC-G1/G2 scraper type self-cleaning filter, which is divided into three series: internal scraping type self-cleaning filters, outside a self-cleaning filter, cylinder scraper type self-cleaning filter.
By mechanical abrasion particles on the surface of the filter to remove impurities, can filter for online.This series of filter for high viscosity material design, suitable for viscosity is as high as 80 x104pa. S, precision range 50-500 um, precision filter, can fast will blow away from the surface of impurities, thus more efficient removal of impurities, suitable for water and various viscous liquid filtration.Effectively for the customer to solve the frequent manual cleaning, investment is large, heavy work, waste materials, etc.
Working principle:
Liquid from imported into, inner surface flow outward from the filter, filter the bottom connection exports, liquid flow from exports, impurity particles were intercepted in the lining surface of the filter element;When filter surface intercepted a certain impurities, set according to differential pressure start timing or cleaning procedure, reducer motor/cylinder driving stick to filter on the surface of the blade rotation, shave their filter inside surface impurities, impurity left filter surface along the blade, with downward liquid fall into the bottom of the filter, the rotation will sweep the board at the bottom of the heavy impurities into dirt cavity, impurities accumulate in sludge deposition chamber, and at the bottom of the filter, open drain valve timing, will contain high concentrations of liquid from the discharge outlet, the other can be recycled.
Technical features and advantages:
1, automatic operation, 24 hour continuous online filtering, put an end to heavy filter replacement cleaning work;
2, using sheet metal scraper/four fluorine scraper, shave their effect is excellent, significantly improve the ability of impurity removal, avoid impurity extrusio;
3, can be added to the washing function, auxiliary cleaning filter element;
4, cover an area of an area small, saving the cost of consumables and environmental treatment cost;
5, small pressure loss of the filter, flow stability, conducive to continuous stable process;
6, airtight filtering, prevent leak dangerous material, production safety and employee health;
7, discharge waste, impurity concentration is high, and can be recycled, reduce the high value material loss;
8, a variety of optional advanced control system, efficient, high reliability, long service life;
9, the standard end cover auxiliary lifting device, easy opening and closing filter.
10, in a certain viscosity medium condition, under the use of the motor can be replaced for the cylinder, avoiding the phenomenon of electric lock, running more stable.
Blade material: PTFE teflon
Power supply voltage, three-phase 380 v, 50 hz (it can customize according to the voltage);
Drainage device: the electric or pneumatic ball valve is recommended.
Filter element | (mesh) | 300 | 200 | 150 | 120 | 100 | 75 | 60 | 50 | 40 | 30 | 20 | 15 | 10 | Application | ||
(μm) | 50 | 75 | 100 | 125 | 150 | 200 | 250 | 300 | 375 | 500 | 750 | 1000 | 1500 | Hard particles | soft paticles | fiber | |
U-M series element | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ||
U-S series element | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ |
Application fields:
▲Application field
▲Bring about polymer
▲Bring about coating
▲Bring about adhesive
▲Bring about plastisol
▲Bring latex paint
▲Bring about resin
▲Bring about ink
▲Bring lubricant
▲Bring about the peanut butter
