Low Noise Hydraulic Plastic Injection Molding Machine , Plastic Mold Making Machine

HCW2000 Hydraulic Plastic Injection Molding Machine With Vickers Valve

Quick Detail:

HCW2000 Plastic Injection Molding Machine is for normal type plastic material injection, e.g. PC, PP, PE, Nylon, A.B.S. PVC etc., this machine is with clamping force 2000tons, there are four available screws, the corresponding real shot weight 8608g, 10226g,11739g,13356g. This machine is mainly used to produce middle&big industrial parts, household appliances and other plastic products.

Competitive advantages:

1. Heaters adopt ceramic, the using life is double than stainless steel.
2. Machine with oil filter system to ensure hydraulic oil clean , to prolong action valves using life.
3. The machine equipped with 7 inch colorful screen controller, brand Techmation from Taiwan, the controller is with several languages include English, French, Spanish, Portuguese, Russian, Arabic etc.
4. The machine equipped with hydraulic protection
5. The machine equipped with double Hydraulic pulling device
6. The machine equipped with double Air Ejector
7. The machine equipped with single slots on the mold plates

--High-precision hydraulic oil filter system, oil temperature /level instant monitoring

--High performance servo motor system, hydraulic components from world famous brand, saves power by 50-80%. Servo motor system with quick response, response time 30-50ms

--Versatile controller with excellent QC monitoring function, temperature detecting function.

--Hydraulic routes with the fewest bents, welding and with the shortest route

Description:

HCW2000 injection molding machine is the type of fully automatic machine, being provided with high
efficiency, high reliability, high speed, low noise, low power consumption and other advantages.
Machine main components adopt world famous brand, e.g.:

• PLC: TECHMATION CONTROLLER(Taiwan)
• AC Contactor: SIEMENS(Germany)
• Travel switch: SCHNEIDER(FRANCE),
• Transducer: NOVOTK (Germany)
• Proportional Valve: HNC(TAIWAN)
• Oil pump: VICKERS(USA)
• Directional Valve: VICKERS(USA)
• High-pressure pipe line: GOOD YEAR (USA)

Specifications :


PLATEN SIDE
