High Precision Flexo Machine with Microcomputer Control , 80m/min

High Precision Flexo Machine with Microcomputer Control , 80m/min

  • High Precision Flexo Machine with Microcomputer Control , 80m/min
  • High Precision Flexo Machine with Microcomputer Control , 80m/min
  • High Precision Flexo Machine with Microcomputer Control , 80m/min
  • High Precision Flexo Machine with Microcomputer Control , 80m/min
High Precision Flexo Machine with Microcomputer Control , 80m/min
Product Details:
Place of Origin: China
Brand Name: LS
Certification: CE
Model Number: YTB
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: wooden pallte
Delivery Time: 30days before deposite
Payment Terms: L/C, T/T
Supply Ability: 20set/month
Contact Now
Detailed Product Description
Print Color: 1. 2. 4 . 6 .8 Print Width: 600mm 800mm 1000mm
Print Speed: 80m/min Machine Speed: 100m/min
High Light:

digital printing machines

,

polygraph flexo printing machine



High Precision Flexo Machine with Microcomputer Control , 80m/min





use



Company is mainly engaged in design and manufacturing of printing machines. It is capable of



independently developing new flexographic printing machines.





The main features:



1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for

group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective

 layer of hard chromium.
7. Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8. With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll



Model

YTB 1000mm

Max. print material width

10 50mm

Printing  width

9 60mm

Printing material

Paper:  50 ~ 35 0g/m2

Printing color

6  color  (6+0)

Printing length

7.5"~ 5 0"(190mm~1 5 00mm)

M e ch a nical speed

9 0m/min

Printing speed

1 0m- 80m/min



Register precision

Longitude:±0.25mm  Transverse:±0.25mm

Rewinder/Unwinder DIA

Φ 12 00mm  (unwinding)
Φ 13 00mm  (rewinding)

Printing plate lifting system

Auto Hydraulic cylinder control printing roll up and down

EPC  system:

Edge Position Controller, 1 PC

Tension system

Automatic tension control for unwinding  1 PCS

Unwinding loading and rewinding unloading way

By air shaft , with  10 kg magnetic 2 pcs
With 1.5 kw  motor compages rewinding

Printing  Pressure

M echanical adjust

Anilxo roll

Standard metal anilxo roll (1 0 0-300PLI)
Or
High: ceramic anilox roller ( 3 00-800lpi), single doctor

 blade

Master motor

3.7Kw TAIWAN BRAND

Drying way

Electrical heat drying

Drying power

24 kw

Blower of nature wind

0.95 Kw x 6 pcs
75W x 12 pcs

Inking motor

Taiwan brand

 Master frequency converter

3.7 kw

Master power

32 Kw

Dimension(L×W×H)

5.4 ×2. 4×  3.2 m



Sample :





High Precision Flexo Machine with Microcomputer Control , 80m/min 0
