200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling

200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling

  • 200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
  • 200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
  • 200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
  • 200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
  • 200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling
Product Details:
Place of Origin: WUXI China
Brand Name: LONGSONG
Certification: CE
Model Number: LS200ZH-A
color: RED|WHITE|Yellow
Displacement: 200cc
Engine Type: 4-Stroke|air-cooled|single cylinder
For the crowd: Men
Fuel: Gas
Load Capacity: 1000kg
Product name: Two Wheel Drive Motorcycles
Use: Loading
Contact Now
Detailed Product Description
High Light:

3 wheel motorcycles

,

three wheeled motorcycle



200cc CDI Motorized Three Wheel Cargo Motor Tricycle With Air Cooling



Description



Model:  LS200ZH-A1

Displacement(cc):   200cc

Ignition System:    CDI

Fuel Type:  Gas/CNG

Fuel Tank:  12L/22L

Clutch Method:manual-hand

Tyre size(F/R)   4.50-12

Design Max speed: ≥50km/h

Load capacity:  1000kg

Cargo box Dimension(mm)(L*W*H)     1700*1250*1400





Applications:

Tricycle can be used for cargo and passengers.





Specifications:

Model

LS200ZH-A1

Engine type

1 cylinder,4stroke,air-cooled

Displacement(cc)

200cc

Ignition System

CDI

Fuel Type:

Gas/CNG

Fuel Tank:

12L/22L

Clutch Method

manual-hand

Transmission system

shaft drive

Brake Mode(F/R)

Mechanical/Power hydraulic

Tyre size(F/R)

4.50-12

Starting system

electric/kick

Suspension

spiral spring with telescopic shock absorber

Design Max speed

≥50km/h

Load capacity

1000kg

Cargo box Dimension(mm)(L*W*H)

1700*1250*1400

Conveyance CKD:

40HQ:  33units

20FT:14units

Color

red/bright red/blue/silver/yellow

●the first class engine low rotating speed ratio, high torque ,highly reliable ,double gearing system

●Use durable bus class framework pipes, plastic coated ensure anti-rusting protection

●Full 2.5-3mm thick automobile class high quality steel sheet body, all panels mould pressured ensure the precision, reinforce works at all weak points ensures better loading capacity.

●Extra strong hydraulic front suspension, smoother driving experience & handling                                                      ●It is a strong and good quality for heavy loading and bad road condition



CE Certificated Battery driven Transport refrigeration units.

cooling 1100w.

All electrical system.

Roof Mounted Condenser.



T110D is the new All Electric unit range to provide outstanding refrigeration capacity for small trucks and vans.

No compressor in the engine compartment is needed, which operation with vehicle battery driven compressor.

The system is powered by the vehicle's battery and controlled by the CORUN controller.

T110D features an Roof Top mounted Condenser and ultra thin ceiling mounted evaporator which increases payload space. .

HFC R-134a.

Automatic hot gas defrost

Compressor: Electrical compressor.

Airflow volume: 800 m³/h (500 cu. ft/min)

Dc voltage options: 12Vdc and 24Vdc

Total current consumption on the road: 12Vdc - 76A 24Vdc - 38A

System Components:

Roof Top Condenser + Ultra Slim Evaporator + Installation kit + In-cab Controller.



Cooling Capacity: (European ATP Standard)

Degrees 0C: 1100W.

Degrees -5C: 950W.



European Fashionable styleand streamline apperance Compatible to vehicles body.

High cooling capacity, more cooling air.

ISO9001/ TS16949/ QS9000/ CE Certification.

Pro-active service, reasonable price, and long life products.
