Air suspension system

Introduction:

Automobile teaching equipment(air suspension system)is equipped with the real part of air suspension system to demonstrate the framework and working process of the system. It has function of setting and solving faults intelligently. Fit for junior senior vocational school, normal education school and training institution needs for teaching theory and service of the system, the testing platform is easy and safe to operate with various functions.

-

basic structure:

Air suspension ECU,compressor,1# height control Valve,2# height control valve,height control Relay,left front suspension control actuator,right front suspension control actuator,left front control sensor,right front control sensor,height control switch,all kinds of stimulate switch signal,date link connector,movable platform and so on

-

Function:

-1. Demonstrate the framework and working process of the system

-2. By operating switch of controlling height of suspension, air suspension ECU will take control of compressor, height control valves, and absorber and so on ,to adjust height of air suspension and rigidity of absorber to show real work process of system.

-3. On the panel of the running stage there was painted the circuit diagram and the diagram is protected with methacrylate and inlayed with aluminum. The learner can compare the diagram and the real to know and analyze the working theory of the controlling system, know and analyze working principle.

-4. The testing platform is installed with testing Terminal, to test signals of sensor, actuator and engine controlling unit, e.g: resistance, voltage, current ,frequency signals.

-5. The panel of testing platform is installed with meter,oil Pressure Gauge, vacuum Pressure Gauge which display the change of rotating speed, oil pressure, Manifold Pressure and so on .

6. (Collocated) The platform was collocated with setting of intelligent faults, as the characteristics below:

A.It adopted the latest MCU technology, digital integrated circuits, with Color Liquid Crystal Display of 320*420 and it is easy to operate.

B.It can set faults of cutting off the connection of any open circuit, line-to-ground short circuit and other faults in any point freely.

C.It can adjust setting of quantity and type of faults points according to usage requirement of the equipment.

D.Installed with communication port, and can be connected to computer to ensure to finish setting up faults and parameter and eliminating faults by using this software.

E.Installed with network port and can be connected with other faults setting equipment to form a network. The main controlling machine will control the functions of faults setting, fault solving, parameter setting, remoter start, information feedback and assessment

F.it is easy and convenient to update the software anytime to the latest version.

G.The base of the testing platform was sealed by steel framework, with plastic painted on the surface. It is very flexible with truckle equipment

H. The platform is equipped with use Introduction and related material.

-

technique parameter:

Panel dimension:1000mm*1000mm*200mm (length*height*width)

Stage dimension:1600mm*1000mm*800mm (length*height*width)

Outer Power:220v alternative current

Working power:12V direct current

Working temperature-4050
